Hanghui-Meat Smoking Machine Manufacturer and Exporter
Hanghui multi-functional meat smoking machine include the functions of cooking, drying and smoking. According to different needs, we can also add the cold smoking and spraying options. This meat smoker is suitable for processing hanging and flat products such as sausages, bacon, fish fillets, chicken legs, chicken wings, duck necks, beef jerky, etc. Meat smokers can be customized single door smoker, double door smoker, with different capacity from 30 per batch to 1000kg per batch.
meat smoker oven technical parameter
| Model | YX-30 | YX-50 | YX-100 | YX-200 | YX-500 | YX-1000 |
|---|---|---|---|---|---|---|
| Capacity | 30kg/batch (Sausage) | 50kg/batch (Sausage) | 100kg/batch (Sausage) | 200kg/batch (Sausage) | 500kg/batch (Sausage) | 1000kg/batch (Sausage) |
| Heating ways | Electric | Electric | Electric | Electric | Electric | Electric |
| Power | 12.5 KW | 16 KW | 22 KW | 26 KW | 50 KW | 120 KW |
| Voltage | 220V-480V | 220V-480V | 220V-480V | 220V-480V | 220V-480V | 220V-480V |
| Temperature | < 150 °C | < 150 °C | < 150 °C | < 150 °C | < 150 °C | < 150 °C |
| Trolley | 670*680*650mm
1 cart |
700*730*915mm
1 cart |
816*860*1150mm
1 cart |
920*930*1380mm
1 cart |
1100*1030*1680mm
2 carts |
1013*1060*1680mm
4 carts |
| Racks | 670*580mm
4 racks |
610*730mm
5 racks |
730*860mm
6 racks |
830*930mm
7 racks |
930*1060mm
8 racks |
930*1060mm
8 racks |
| Furnace size | 1020*1070*1450mm | 1060*1500*1790mm | 1200*1600*2100mm | 1350*1800*2600mm | 1450*3330*3100mm | 4430*2060*3100mm |
| Weight | 320kg | 460kg | 650kg | 900kg | 2200kg | 2000kg |
smoke oven machine Introduction
This smoke oven machine mainly includes: smoke generator , heating system, smoking system, air circulation and exhaust system, drying system, cleaning system and PLC electrical control components. The smoke chamber is made entirely of 304 stainless steel, meet food safe and easy to clean. The insulation materials are made of high-quality imported material,which ensures fast heating and good thermal insulation.
Widly Application of Meat smoking machine
This meat smoking machine is widly suitable for drying and smoking for Ham, Pork, Poultry, Meat, Fish, Chicken, Chicken wings, Duck, Duck neck, Beef jerky, Biltong, Meat sticks, Mutton, Sausage, Bacon and so on. It is one of the necessary equipment for meat processing.
Meat smoking machine By different Application
